BYC Series Film Coating Machine for Pharmaceutical

Name: BYC Series
Brand: CECLE
Price: 2850.0 USD
Availability: InStock

$2,850.00 USD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Model BYC-300 BYC-400 BYC-600 BYC-800 BYC-1000 BYC-1250

Shipping method by sea to port(20-30days)

Quick Answer: The CECLE BYC Series Coating Machine is high-efficiency processing equipment that integrates sugar coating, film coating, and polishing functions, specifically designed for the surface coating of various.

CECLE BYC Series vs. Traditional / Generic Alternative

Where the CECLE BYC Series stands out against manual or generic film coating machines — measured on the dimensions buyers care about most.

Pressure Consistency

CECLE BYC SeriesThe CECLE Film Coating Machine holds working pressure steady across batches, cutting weak-output rejects.

Inconsistent Contact PressureForce drifts part to part, causing weak adhesion, wrinkled labels or misalignment.

Output Speed & Throughput

CECLE BYC SeriesIt is tuned for continuous commercial throughput with minimal idle time.

Slow Manual CyclingLoading and cycling depend on operator pace, limiting real throughput and raising labor cost.

Operational Mechanism & Drive

CECLE BYC SeriesIts drive removes operator-dependent variation, so output stays consistent.

Manual Lever OperationOutput depends on operator strength and drifts between shifts.

Chassis Rigidity & Vibration Resistance

CECLE BYC SeriesThe frame is built rigid to damp vibration and hold alignment under load.

Lightweight Sheet Metal ConstructionProne to chassis flex, frame warping over time, and drifting label placement.

Technical Specifications

Parameter	BYC-300	BYC-400	BYC-600	BYC-1000	BYC-1500
Capacity	2 kg/time	2-5 kg/time	8-15 kg/time	50-70 kg/time	150-250 kg/time
Pot Tilt	42°	42°	30°	30°	30°
Speed	0-46 r/min	0-46 r/min	0-40 r/min	0-32 r/min	0-28 r/min
Motor Power	0.55 kw	0.37 kw	0.75 kw	1.5 kw	5.5 kw
Heating Power	500 w	1 kw	2 kw	4 kw	6 kw
Fan Power	40 w	60 w	100 w	200 w	4000 w
Spray Gun	RA-C1	RA-C1	RA-C1	Customized	Customized
Weight	65 KG	100 KG	150 KG	200 KG	600 KG

Compatible Applications & Materials

industrial products — primary target products for this Film Coating Machine line
Standard industrial materials compatible with the machine's rated spec range
B2B production lines and contract manufacturing workshops

Standard Operating Procedure (SOP)

Setup: connect the required power / air supply and verify the control display.
Parameter preset: set speed / temperature / pressure per the product spec.
Material loading: place the product in the correct fixture / mold slot.
Execution: start the cycle; monitor for stable, repeatable output.
Quality check: inspect the first units; adjust if deviation appears.
Safety & cooldown: use Emergency Stop on abnormality; allow cooldown before maintenance.

Engineering FAQ

What temperature control functions does the BYC series coating machine have?
A: The heating temperature of the machine can be freely adjusted between 0-100°C according to process requirements. After the heating function is turned off, the equipment can introduce cold air through the internal system for cooling. Both heating and cooling functions can be activated at any time, greatly enriching the flexibility of coating operations.

What accessories are included when the machine is shipped? Is the packaging safe?
A: Before leaving the factory, all equipment will be fully encapsulated in sturdy, industrial-grade fumigation-free wooden cases (Wooden case), which can completely withstand the bumps of long-distance sea freight. The packaging box will be fully equipped with the standard spare parts (spare parts) and dedicated installation tools required for the machine's operation.

What is the after-sales service and warranty policy for the equipment?
A: The standard warranty period for the entire machine is one year. During the warranty period, as long as any equipment damage occurs under normal operation according to the instruction manual, we will provide free repair services or free replacement of damaged parts, and the customer only needs to bear the shipping cost from China to their local area. After the warranty period expires, we will continue to provide you with lifelong maintenance and technical support services.

If we need engineer assistance, how are the costs calculated?
A: If you need our engineers to travel locally to provide on-site technical assistance during the installation or debugging phase, the engineers' round-trip travel expenses will be borne by the customer.
