Full electric forklift stand-on electric lifting stacker Hydraulic Pallet Full Electric Stacker

Full electric forklift stand-on electric lifting stacker Hydraulic Pallet Full Electric Stacker

Regular price $5,699.00 USD
Regular price Sale price $5,699.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.
Model
Shipping Method

1.Humanized design of the operation desk, equipped with emergency stop switch, only need to press the economic situation can power off the automatic brake, to ensure the safety of the operator

2.The handle is designed with glue,anti-slip and comfortable, it integrates lifiting, forward, backward, horn and emergency braking in one, convenient and flexible.

3.Multi-chip composite chain, smooth transmission, strong bearing capacity, is several times the ordinary chain.

Model

SD-10

SD-10

SD-10

SD-20

SD-20

Rated Load

1000kg

1000kg

1000kg

1000kg

1000kg

Standard door stand height

1600mm

2000mm

2500mm

1600mm

2000mm

Maximum height of the vehicle when the gantry is in operation

2180mm

2180mm

2180mm

2180mm

2180mm

Static height of the vehicle when the gantry retracted

2100mm

2100mm

2100mm

2100mm

2100mm

Load center distance

500mm

500mm

500mm

500mm

500mm

Minimum height of fork

85mm

85mm

85mm

85mm

85mm

The full length pedal is

2000/2400mm

2000/2400mm

2000/2400mm

2000/2400mm

2000/2400mm

The vehicle width

850mm

850mm

850mm

850mm

850mm

Miniumum turning radius

1500mm

1500mm

1500mm

1500mm

1500mm

Maximum speed full/no load

4/6 km/h

4/6 km/h

4/6 km/h

4/6 km/h

4/6 km/h

Maximum lifting speed full load/no

80/130 mm/s

80/130 mm/s

80/130 mm/s

80/130 mm/s

80/130 mm/s

Maximum descent speed full load/no

100/90 mm/s

100/90 mm/s

100/90 mm/s

100/90 mm/s

100/90 mm/s

Drive motor/hoist motor

1.2/2.2 kw

1.2/2.2 kw

1.2/2.2 kw

1.2/2.2 kw

1.2/2.2 kw

Battery voltage/capacity

24/190 V/Ah

24/190 V/Ah

24/190 V/Ah

24/190 V/Ah

24/190 V/Ah

Weight

710kg

720kg

720kg

750kg

750kg
