F6-SEMI Filling Alcohol Machine for Liquids (Pneumatic Drive)

$643.00 USD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Size F6-100 F6-300 F6-500 F6-1000 F6-2500 F6-5000

Shipping method by express(7-10 days)

Place of shipment shipping from China

Quick Answer: The CECLE F6-SEMI semi-automatic Pneumatic Horizontal Liquid Filling.

CECLE F6-SEMI vs. Traditional / Generic Alternative

Where the CECLE F6-SEMI stands out against manual or generic machine — measured on the dimensions buyers care about most.

Operational Mechanism & Drive

CECLE F6-SEMIFull Pneumatic is the biggest selling point of this series — the first 5 advantages below all revolve around it. No electricity at all — full pneumatic drive — No motor, no electronic controls, no wiring.

Manual Lever / Foot UnitsOutput depends on operator strength and drifts between shifts; no stable drive control.

Pressure Consistency

CECLE F6-SEMIStable 0.4–0.6 MPa Air Pressure: Pneumatic or servo-controlled force stays consistent across batches.

Inconsistent Spring/Manual PressureForce drifts with operator fatigue and batch size, causing weak seals and rejects.

Output Speed & Throughput

CECLE F6-SEMIIt is tuned for continuous commercial throughput with minimal idle time.

Slow Manual CyclingLoading and cycling depend on operator pace, capping real throughput and raising labor cost.

Chassis Rigidity & Vibration Resistance

CECLE F6-SEMIThe frame is built rigid to damp vibration and hold alignment under load.

Lightweight Sheet Metal ConstructionProne to chassis flex, frame warping over time, and seal leakage.

Technical Specifications

Parameter	F6-50	F6-100	F6-300	F6-500	F6-1000	F6-2500	F6-3000	F6-5000
Filling Range	5–50 ml	10–100 ml	30–300 ml	50–500 ml	100–1000 ml	250–2500 ml	300–3000 ml	500–5000 ml
Filling Speed	10–40 cycles/min	10–40 cycles/min	10–30 cycles/min	10–30 cycles/min	10–40 cycles/min	10–30 cycles/min	10–30 cycles/min	10–40 cycles/min
G.W./N.W.	30/22 kg	30/22 kg	30/22 kg	30/22 kg	30/22 kg	40/32 kg	40/32 kg	40/32 kg
Packaging Dimension L×W×H	101×33×35 cm	101×33×35 cm	101×33×35 cm	101×33×35 cm	101×33×35 cm	122×40×39 cm	122×40×39 cm	122×40×39 cm

Customer Fill Volume	Recommended Model	Customer Fill Volume	Recommended Model
Sample packs / small bottles (5–50 ml)	F6-50	Jugs / large bottles (100–1000 ml)	F6-1000
Small trial bottles (10–100 ml)	F6-100	Gallon-size (250–2500 ml)	F6-2500
Regular bottles (30–300 ml)	F6-300	Large buckets / drums (300–3000 ml)	F6-3000
Household / large bottles (50–500 ml)	F6-500	Large buckets / drums (500–5000 ml)	F6-5000

No.	Model	Filling Range
1	F6-50	5–50 ml
2	F6-100	10–100 ml
3	F6-300	30–300 ml
4	F6-500	50–500 ml
5	F6-1000	100–1000 ml
6	F6-2500	250–2500 ml
7	F6-3000	300–3000 ml
8	F6-5000	500–5000 ml

Pre-installation requirements: Air Pressure: 0.4–0.6 MPa. External air compressor (3 HP / 2.2 kW or above) required.

Compatible Applications & Materials

industrial products — primary target products for this Machine line
Standard industrial materials compatible with the machine's rated spec range
B2B production lines and contract manufacturing workshops

Standard Operating Procedure (SOP)

Requirement confirmation: fill volume per cycle (ml), speed requirements, product characteristics (flowability / corrosiveness → 304 or custom 316), power availability and explosion-proof requirements in the workshop, and whether the customer already has an air compressor
Model recommendation: recommend the corresponding model from F6-50 to F6-5000 per the table in 4.1
recommend 2/4/6-head machines for high-capacity needs
Companion equipment: if the customer has no air compressor, recommend one (0.4–0.6 MPa, airflow covering the machine's air consumption) so the machine can run on arrival
Technical details locked down: material (304 / custom 316 ), nozzle diameter (3–12 mm), seals (silicone / corrosion-resistant rubber), number of filling heads (single / 2 / 4 / 6), foot pedal vs
Quotation &amp
terms: MOQ 1 unit

Engineering FAQ

What does the 0.4–0.6 MPa Air Pressure requirement mean for the F6-SEMI?
A: The 0.4–0.6 MPa Air Pressure is the working condition needed for consistent, repeatable results. Operators must supply a stable source at this level; fluctuations cause defects.

Does the F6-SEMI need an external air compressor?
A: Yes. The F6-SEMI is pneumatically driven and requires a stable external air supply at the specified pressure. CECLE recommends a compressor sized for continuous duty to hold stable output.

What routine maintenance keeps the F6-SEMI stable for long production runs?
A: Keep the working area clean, verify the rated power/air supply before each shift, and inspect wear parts per the technical manual. Stable input conditions are the main factor in consistent output and long service life.

Which product sizes and formats can the F6-SEMI handle?
A: The machine is configured for its rated specification range (see Technical Specifications). For formats outside the standard range, CECLE can advise on tooling or model selection.
