AD-220 Automatic Tabletop Round Bottle Labeling Machine - Industrial Grade Solution
The AD-220 Automatic Tabletop Round Bottle Labeling Machine is a high-performance, industrial-grade solution engineered for the precise labeling of cylindrical containers in the pharmaceutical, food, daily chemical, and fine chemical industries. Compact yet powerful, this tabletop system is ideal for small-to-medium factories and studios, offering a throughput of 30 to 60 bottles per minute with robust servo-driven accuracy.
Technical Documentation & Support
For detailed electrical schematics, maintenance manuals, and comprehensive operating guides for this machine, please visit our Official Technical Documentation Portal.
I. Product Overview & Use Scenarios
Widely applicable to the daily chemical, pharmaceutical, food, and fine chemical industries. Specifically designed for precise labeling of cylindrical containers such as hand sanitizer bottles, disinfectant bottles, small cosmetic vials, medicine bottles, cans, and seasoning bottles, ensuring high production efficiency and regulatory compliance.
II. Core Advantages
- High Customizability: Supports transparent label sensors, optional ribbon coders for date printing, high-precision pneumatic positioning systems for dual-labeling or orientation, and line expansion modules like bottle spacing wheels and unscramblers.
- Multi-Mode Labeling: Supports single and dual-label modes to meet diverse product presentation and regulatory labeling requirements.
- Compact Tabletop Design: Occupies minimal space while delivering heavy-duty performance, making it ideal for small-to-medium factories, studios, and laboratories.
- Stable & Efficient Servo Drive: Equipped with a high-performance servo drive system to guarantee wrinkle-free and bubble-free application with precise positioning consistency.
III. Technical Specifications
| Item | Technical Details |
|---|---|
| Applicable Bottle Diameter | 30-100 mm (customizable) |
| Label Size | Width: 10-120 mm / Length: 15-300 mm |
| Labeling Speed | 30-60 bottles/minute |
| Labeling Accuracy | Within ±1 mm |
| Coding Capability | Supports optional thermal transfer ribbon coder |
| Power Supply & Weight | AC 110V/220V / Approx. 140 kg |
| Dimensions | 1320 × 820 × 950 mm |
IV. Workflow
- Automatic Feeding: Bottles are placed onto the conveyor manually or via an automated unscrambler.
- Positioning & Spacing: Spacing wheels maintain intervals, and the pneumatic system securely aligns bottles for precise or dual-label application.
- Label Peeling & Coding: Sensors trigger labeling while the ribbon coder prints batch details directly onto the label.
- Smooth Application: Bottles rotate through the application unit for a smooth, wrinkle-free, and bubble-free finish.
- Finished Product Collection: Labeled products are automatically discharged via the exit plate.
V. Frequently Asked Questions (FAQ)
Q: Can the machine handle bottles with specific markings that need alignment?
A: Absolutely. We support adding a pneumatic positioning system that holds the bottle steady, ensuring the label is applied precisely at your designated mark.
Q: How clear is the printing from the ribbon coder?
A: We use professional thermal transfer ribbon coding technology. The printed dates and batch numbers are very clear, durable, and do not carry the risk of ink spreading like inkjet coders.
