CECLE Machine

PCK-1 Spring Making roll Wrapper for Food Processing (Automatic)

$3,200.00 USD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Model PCK-1

Single row roller length 22cm/8.6" 23-30cm/9.05-11.8" 31-40cm/12.2-15.7"

Shipping method By sea to door about (45-65days)

Quick Answer: The CECLE PCK-1 commercial fully automatic roast duck pancake, spring roll wrapper, and crepe making machine is specially designed for food processing factories, central kitchens, large restaurant chains.

CECLE PCK-1 vs. Traditional / Generic Alternative

Where the CECLE PCK-1 stands out against manual or generic roll wrapper — measured on the dimensions buyers care about most.

Output Speed & Throughput

CECLE PCK-1For restaurants or food factories with a massive daily consumption of roast duck pancakes, spring roll wrappers, or curry puff wrappers, fully automatic equipment is the only way to achieve a leap in.

Slow Manual CyclingLoading and cycling depend on operator pace, limiting real throughput and raising labor cost.

Precision & Consistency

CECLE PCK-1End-to-End High Standardization : Precise speed and constant temperature control ensure that every wrapper has a uniform thickness (adjustable from 0.3mm-2.0mm), consistent doneness, and no burning.

Analog / Blind OperationNo real-time parameter feedback; operators guess settings, so quality drifts batch to batch.

Pressure Consistency

CECLE PCK-1The CECLE roll Wrapper holds working pressure steady across batches, cutting weak-output rejects.

Inconsistent Contact PressureForce drifts part to part, causing weak adhesion, wrinkled labels or misalignment.

Operational Mechanism & Drive

CECLE PCK-1Its drive removes operator-dependent variation, so output stays consistent.

Manual Lever OperationOutput depends on operator strength and drifts between shifts.

Technical Specifications

Features	Pure Manual Rolling/Baking	Fully Automatic Commercial Wrapper Machine
Capacity & Efficiency	Extremely low (highly dependent on worker proficiency)	Extremely high (continuous assembly line operation)
Labor Requirement	Requires multiple skilled pastry chefs	1 operator (just add batter and collect)
Product Consistency	Poor (uneven thickness, prone to burning)	Extremely high (adjustable thickness, constant temp prevents burning)
Safety Factor	Prone to burns from hot iron pans or ovens	Automated operation, isolates high-temperature baking area
Target Audience	Small private workshops, family stalls	Food factories, central kitchens, roast duck restaurants

Core Technical Indicators	Specifications
Equipment Models	Custom production models (Pure Electric / Gas Heating optional)
Machine Material	High-quality 304 Stainless steel
Function Integration	Auto pumping / Constant temp drum baking / Auto demolding / Conveying & collecting
Wrapper Thickness	0.3mm - 2.0mm (Adjustable based on batter & speed)
Shape Specifications	Round roast duck pancake / Square spring roll wrapper, etc. (Customized according to mold specs)
Shipping & Delivery	By sea to door about (35-40 days)
Applicable Environment	Central kitchens, food processing factories, restaurant chains (Commercial use)

Compatible Applications & Materials

industrial products — primary target products for this roll Wrapper line
Standard industrial materials compatible with the machine's rated spec range
B2B production lines and contract manufacturing workshops

Standard Operating Procedure (SOP)

The following is a core operation and parameter setting guide based on real machine startup debugging:
Pre-startup Preparation Check whether the surface of the machine drum is clean, and whether the conveyor belt and batter pump pipeline are connected correctly without foreign objects
Set the baking temperature of the drum according to the wrapper requirements, and turn on the heating switch to preheat (usually preheated to 120°C - 160°C)
Before preheating is complete, a very small amount of edible demolding oil can be evenly applied to the drum surface
Feeding and Operation Batter Pre-processing : Mix flour and water according to a strict ratio to make a batter, let it stand to remove bubbles (the batter needs to have good fluidity and no lumps), and pour it into the machine's stainless steel batter bucket
Start Forming : After the drum temperature reaches the set value, turn on the drum rotation motor, and then turn on the batter delivery pump
The batter will automatically and evenly adhere to the drum surface

Engineering FAQ

Can this machine make spring roll wrappers or roast duck pancakes of different sizes and shapes?
A: Yes. The forming method (round nozzle or square cutter) and the effective width of the drum can be factory-customized according to your specific needs. Whether it's round roast duck pancakes, square spring roll wrappers, or curry puff wrappers, they can all be perfectly produced.

How is the thickness of the wrappers adjusted?
A: The thickness of the wrapper is mainly determined by the batter concentration (water-to-flour ratio) and the heating rotation speed of the drum. The microcomputer control panel supports stepless variable frequency speed regulation. You can easily produce standardized wrappers with a thickness between 0.3mm and 2mm by fine-tuning the rotation speed and batter recipe.

Is the machine troublesome to clean? How to clean the batter in the pipeline?
A: Very simple. The batter delivery pipeline supports water-pumping circulating self-cleaning. Just put the suction pipe into clean water and start the material pump to flush it clean. The drum surface can be wiped with a flexible damp cloth after cooling. Since the body is all 304 stainless steel, the exterior is stain-resistant and easy to clean.

What routine maintenance keeps the PCK-1 stable for long production runs?
A: Keep the working area clean, verify the rated power/air supply before each shift, and inspect wear parts per the technical manual. Stable input conditions are the main factor in consistent output and long service life.

Which product sizes and formats can the PCK-1 handle?
A: The machine is configured for its rated specification range (see Technical Specifications). For formats outside the standard range, CECLE can advise on tooling or model selection.
