ZP9 Rotary Pharmaceutical Candy Lab Laboratory Tablet Press Machine for Industrial Use

$4,599.00 USD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Model ZP-5 by sea ZP-7 by sea ZP-9 by sea

Quick Answer: The CECLE ZP9 zP-9 is a continuously and automatically operating rotary tablet press, specifically designed to efficiently press various granular raw materials into round or irregular-shaped tablets.

CECLE ZP9 vs. Traditional / Generic Alternative

Where the CECLE ZP9 stands out against manual or generic tablet press machines — measured on the dimensions buyers care about most.

Pressure Consistency

CECLE ZP9Stable 60 kn Max. Pressure: Pneumatic or servo-controlled force stays consistent across batches.

Inconsistent Spring/Manual PressureForce drifts with operator fatigue and batch size, causing weak seals and rejects.

Output Speed & Throughput

CECLE ZP9Rated 16,200 pcs/h Estimated Capacity: Built for steady commercial output with minimal idle time.

Slow Manual CyclingLoading and cycling depend on operator pace, capping real throughput and raising labor cost.

Operational Mechanism & Drive

CECLE ZP9Purpose-Built Power Supply: 110V / 220V / 380V (Customizable) drive delivers steady, operator-independent output.

Manual Lever OperationOutput depends on operator strength and drifts between shifts.

Chassis Rigidity & Vibration Resistance

CECLE ZP9Industrial-Reinforced Frame: 300 KG Weight chassis eliminates vibration and keeps seals tight.

Lightweight Sheet Metal (<150 kg)Prone to chassis flex, frame warping over time, and seal leakage.

Technical Specifications

Specification	Value & Unit
Standard Number Of Molds	9 sets ( See Q&A below for details )
Max. Pressure	60 kn
Max. Tablet Diameter	20 mm (0.8 in)
Max. Filling Depth	15 mm (0.6 in)
Estimated Capacity	16,200 pcs/h
Power Supply	110V / 220V / 380V (Customizable)
Net Weight	300 KG (661.4 lb)
Dimensions	480 × 630 × 1100 mm (18.9 × 24.8 × 43.3 in)
Delivery Time	Ready for delivery within 30 - 60 days

Pre-installation requirements: Power Supply: 110V / 220V / 380V (Customizable); Net Weight: 300 KG (661.4 lb); Dimensions: 480 × 630 × 1100 mm (18.9 × 24.8 × 43.3 in).

Compatible Applications & Materials

industrial products — primary target products for this Tablet Press Machine line
Standard industrial materials compatible with the machine's rated spec range
B2B production lines and contract manufacturing workshops

Standard Operating Procedure (SOP)

Setup: connect the required power / air supply and verify the control display.
Parameter preset: set speed / temperature / pressure per the product spec.
Material loading: place the product in the correct fixture / mold slot.
Execution: start the cycle; monitor for stable, repeatable output.
Quality check: inspect the first units; adjust if deviation appears.
Safety & cooldown: use Emergency Stop on abnormality; allow cooldown before maintenance.

Engineering FAQ

Is the number of molds installed on the machine turret fixed?
A: No, it is not fixed. The actual number of molds installed on a rotary tablet press mainly depends on the size of your customized tablets (i.e., punches and dies). Simply put: the larger the customized mold size, the fewer the number of molds that can be accommodated on the turret; conversely, the smaller the mold size, the more molds can be installed . The "9 sets" in the technical parameter table is a standard configuration reference for this model at regular medium sizes.

This machine is classified as pharmaceutical equipment. Do I need special qualifications for import customs clearance? What if I don't have them?
A: Yes, the ZP series rotary tablet press is classified as professional pharmaceutical equipment in international trade. Under normal circumstances, the destination country's customs will require the consignee to have corresponding import qualifications for medical or pharmaceutical equipment. If your company or you as an individual currently do not possess the relevant import qualifications, please contact our sales representatives directly . We have extensive experience in cross-border transportation of large machinery and can match you with and provide corresponding special logistics channels, such as double clearance with tax included (e.g., DDP), to help you smoothly solve customs clearance difficulties and ensure the goods are safely delivered to your door.

What does the 60 kn Max. Pressure requirement mean for the ZP9?
A: The 60 kn Max. Pressure is the working condition needed for consistent, repeatable results. Operators must supply a stable source at this level; fluctuations cause defects.

What routine maintenance keeps the ZP9 stable for long production runs?
A: Keep the working area clean, verify the rated power/air supply before each shift, and inspect wear parts per the technical manual. Stable input conditions are the main factor in consistent output and long service life.

Which product sizes and formats can the ZP9 handle?
A: The machine is configured for its rated specification range (see Technical Specifications). For formats outside the standard range, CECLE can advise on tooling or model selection.
