AD-50 Semi-Automatic Desktop Capping Machine for Round Plastic Bottles
AD-50 Semi-Automatic Desktop Capping Machine for Round Plastic Bottles
Couldn't load pickup availability
Key Advantages of the CECLE AD-50
- Desktop Format: the whole unit sits on a bench, ideal for pilot runs and small-batch work.
- Round and Flat Bodies: accepts round or flat bottles from 30 to 120 mm in diameter.
- Broad Bottle Material Range: runs plastic, PET and glass bottles without changing the drive.
- Electric Operation: 0.85 kW single-phase drive at 220 V or 110 V, no compressor needed.
Technical Specifications
| Specification | Value & Unit |
|---|---|
| Model | AD-50 |
| Working Speed | 20-50 times/min |
| Power | 0.85 kW |
| Voltage | AC 220 V / 110 V 50 / 60 Hz |
| Applicable Cap Size | 20-50 mm |
| Applicable Bottle Diameter | 30-120 mm |
| Automation Grade | semi automatic G.W. / N.W: 150kg |
Pre-installation requirements: Power: 0.85 kW; Voltage: AC 220 V / 110 V 50 / 60 Hz; Automation Grade: semi automatic G.W. / N.W: 150kg
Compatible Applications & Materials
- Round plastic bottles with 20-50 mm screw caps
- Flat and oval bottles within the 30-120 mm body range
- Tablet, liquid and solid filling lines that need a repeatable closing torque
Related CECLE Machines
Request a Quote
Send your container drawings, cap size and target output to CECLE for a tailored configuration, lead time and factory-direct quotation.
Original Equipment Notes
ROUND PLASTIC BOTTLE DESKTOP CAPPING MACHINE, TWIST OFF CAPPING MACHINE
|
Model:
|
AD-50
|
|
Speed:
|
20-50 times/min
|
|
Power:
|
0.85kw
|
|
Voltage:
|
AC 220v/110v 50/60hz
|
|
Screw cap dimension:
|
20-50mm
|
|
Screw bottle diameter:
|
30-120mm
|
|
Automatic grade:
|
semi automatic
|
|
G.W./N.W:
|
150kg
|
|
Packaging dimension:
|
1200*600*650mm
|
For round caps made of plastic
Electric powder mode
Options: 220V/110V voltages.EU,UK,UC Plu
Screw cap dimension:20-50mm
Application:
It can meet the capping of round bottle or flat bottle, easy to operate, safe and stable in production;
The capping machine is suitable for capping plastic bottles, glass bottles, PET bottles and other bottles of various materials and shapes. It is a new generation of capping equipment designed for the automatic capping process of tablet production lines and liquid and solid filling lines. It overcomes the shortcomings of intermittent capping machine with slow capping speed, loose capping and small scope of application, and is also superior to the limitations of rotary capping machine with small scope of application and frequent mold replacement.
