HP-25100 Large Format Heat Press Machine for Lanyards (Manual)

Name: HP-25100
Brand: CECLE
Price: 1699.0 USD
Availability: InStock

$1,499.00 USD

Sale Sold out

Taxes included. Shipping calculated at checkout.

Model HP-25100

Shipping Method By sea to door(About 35-55 days)

Quick Answer: The CECLE HP-25100 is an ultra-long-format manual lanyard heat press machine designed for one-pass, seamless heat transfer onto long-strip substrates such as woven webbing, lanyards, ribbons, shoelaces.

CECLE HP-25100 vs. Traditional / Generic Alternative

Where the CECLE HP-25100 stands out against manual or generic heat press machines — measured on the dimensions buyers care about most.

Output Speed & Throughput

CECLE HP-25100One-Pass, Zero Splicing : 100 cm formed in a single pass. Competitors' short-size presses require moving back and forth and segment pressing, where color difference, misalignment, and missing white are hard to.

Slow Manual CyclingLoading and cycling depend on operator pace, limiting real throughput and raising labor cost.

Pressure Consistency

CECLE HP-25100The CECLE Heat Press Machine holds working pressure steady across batches, cutting weak-output rejects.

Inconsistent Contact PressureForce drifts part to part, causing weak seals or incomplete transfer.

Operational Mechanism & Drive

CECLE HP-25100Purpose-Built Voltage: 110V/220V drive delivers steady, operator-independent output.

Manual Lever OperationOutput depends on operator strength and drifts between shifts.

Chassis Rigidity & Vibration Resistance

CECLE HP-25100Industrial-Reinforced Frame: 90KG/198LB Gross Weight chassis eliminates vibration and keeps seals tight.

Lightweight Sheet Metal (<50 kg)Prone to chassis flex, frame warping over time, and seal leakage.

Technical Specifications

Items	Specifications
Model	HP-25100
Heat Platen Size	25×100CM/9.8×39.4"
Voltage	110V/220V
Power	1800W(110V)/2400W(220V)
Temperature Range	0-220℃
Heat-up Time	10-15 minutes
Packaging Dimension	110×85×55CM/43.3×33.5×21.7"
Gross Weight	90KG/198LB

Pre-installation requirements: Voltage: 110V/220V; Power: 1800W(110V)/2400W(220V); Packaging Dimension: 110×85×55CM/43.3×33.5×21.7"; Gross Weight: 90KG/198LB.

Compatible Applications & Materials

industrial products — primary target products for this Heat Press Machine line
Standard industrial materials compatible with the machine's rated spec range
B2B production lines and contract manufacturing workshops

Standard Operating Procedure (SOP)

Preheat : Connect the power and turn on
set the target temperature and countdown time on the controller
wait 10–15 minutes for it to heat up to working temperature
Adjust Pressure : Rotate the top pressure knob to a suitable gear (a small trial press is recommended before formal production)
Print Pattern : Design the pattern on a computer and print it with an inkjet printer + sublimation paper + sublimation ink
Use only after the ink is completely dry
Load Material : Lay the lanyard flat on the heating plate, align the pattern paper face-down precisely, and fix both ends with high-temperature-resistant tape to prevent shifting

Engineering FAQ

How do I switch between Celsius and Fahrenheit?
A: Long-press the SET key for a few seconds until LOY appears on the display; press the ▼ key until 88 appears; long-press SET again for a few seconds until CF shows; press ▲ or ▼ to switch 0 (Celsius) / 1 (Fahrenheit) ; long-press SET for 3 seconds to confirm and exit.

Can this machine be used with 110V voltage in the United States?
A: Absolutely. We can provide you with customized 110V (North American standard) and 220V (European/Asian standard) models, equipped with power plugs that comply with your national standards.

What power supply does the HP-25100 require?
A: The HP-25100 runs on 110V/220V Voltage. Ensure the facility provides a stable supply at this rating; voltage mismatch can damage the drive or reduce performance.

What peripheral equipment should be prepared for the HP-25100?
A: Beyond the rated 110V/220V Voltage supply, prepare the standard fixtures/molds for your product format and a clean, stable workbench. No special external compressor is required for this electric model.

What routine maintenance keeps the HP-25100 stable for long production runs?
A: Keep the working area clean, verify the rated power/air supply before each shift, and inspect wear parts per the technical manual. Stable input conditions are the main factor in consistent output and long service life.

Which product sizes and formats can the HP-25100 handle?
A: The machine is configured for its rated specification range (see Technical Specifications). For formats outside the standard range, CECLE can advise on tooling or model selection.
