CECLE Machine
TP1650F-CS Pneumatic Top Press Pallet Stretch wrapping Machine, Semi-automatic Stretch Film Wrapper Packing Machine
TP1650F-CS Pneumatic Top Press Pallet Stretch wrapping Machine, Semi-automatic Stretch Film Wrapper Packing Machine
Regular price
$7,199.00 USD
Regular price
Sale price
$7,199.00 USD
Taxes included.
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Semi-automatic Pneumatic Top Press Pallet Stretch Wrapping Machine
Detail:
1.PLC programmable control:The operation is simple.The number of top and bottom winding layers, times, over-top time, and number of reinforcement layers 0-9 can be set directly on the panel.
2.Pneumatic top press device:Top press provides extra pressure on top of loads to improve the stability during wrapping process,make loose goods less likely to slip.
3.Pre-stretched film frame:Film frame power pre-stretching mechanism. Film carriage with powered rollers pre-stretch system (DC motor) pre-stretch film up to 250 - 300%.
| Model | TP1650F-CS |
| Voltage | 220V |
| Power | 1.55KW |
| Turntable diameter | 1650MM/65" |
| Pressure height | 1400-1800MM/55.1*70.9" |
| Column height | 2400MM/94.5" |
| Max packaging size | (500-1100)MM*(500-1200)MM |
| Turntable height | 85MM/3.3" |
| Load capacity | 2000KG/4409LB |
| Turntable speed | 0-12 rpm |
| Air pressure | 0.4-0.7MPa |
| Stretch wrap film | 15-35μm thickness (recommended 25μm) |
| Machine size | 255*165*349CM/ 100.4*65*137.4" |
| Weight | 700KG/1543LB |
