CECLE Machine

Cartoning machine, Fully Automatic Bottle Cartoning Machine ,Food Paper Box Packing Machine, Cardboard box cartoner

Cartoning machine, Fully Automatic Bottle Cartoning Machine ,Food Paper Box Packing Machine, Cardboard box cartoner

Regular price $19,800.00 USD
Regular price Sale price $19,800.00 USD
Sale Sold out
Tax included. Shipping calculated at checkout.
Model
Shipping Method
Shipping From

Cartoning machine, Fully Automatic Bottle Cartoning Machine ,Food Paper Box Packing Machine, Cardboard box cartoner



This cartoning machine is suitable for boxing and packaging of cosmetics, medicines, food, hardware, etc. It can automatically complete the folding of instructions, unfold the carton, box items, print batch numbers, and seal. Using PLC control, photoelectric monitoring of the movement of each part, if there is an abnormality in operation, it can automatically stop and display the cause, so as to eliminate the fault in time.



Model:
CM-120 CM-130
CM-150
Packaging Speed:
30-100times/min
30-100times/min
30-100times/min
Suitable box size:
L80-150mm/3.1''-5.9''
W30-90mm/1.2''-3.5''
H30-80mm/1.2''-3.1''
L80-150mm/3.1''-5.9''
W30-90mm/1.2''-3.5''
H30-80mm/1.2''-3.1''
L80-150mm/3.1''-5.9''
W30-90mm/1.2''-3.5''
H30-80mm/1.2''-3.1''
Sealing method: Folding/Gluing Folding/Gluing Folding/Gluing
Air consumption:
20m³/h 20m³/h
20m³/h
Air pressure:
0.6~0.8Mpa 0.6~0.8Mpa
0.6~0.8Mpa
Power:
1.5kw
1.8kw
2.0kw
Voltage:
110/220V 50-60hz 110/220V 50-60hz 110/220V 50-60hz
Weight:
1200kgs/2645lbs 1300kgs/2866lbs
1500kgs/3306lbs
Packaging dimension:
3100*1600*1700mm
(10'*5.2'*5.5')
3100*1600*1700mm
(10'*5.2'*5.5')
3100*1600*1700mm
(10'*5.2'*5.5')



Cartoning machine

Cartoning machine
